Envirocoustic™ Wood Wool Lay-In Ceiling Tiles

Envirocoustic Wood Wool Lay-In Ceiling Tiles

Envirocoustic™ Wood Wool Lay-In ceiling tiles lead the acoustical-panel products category as an eco-friendly, high-performing, and cost-effective sound absorber that manages echo and reverberation to improve the acoustics in a room or space. Ecologically, Envirocoustic Wood Wool is simple to produce with three natural ingredients: wood fiber, water and Portland cement. Envirocoustic Wood Wool Lay-In ceiling tiles are Class A fire-rated and pass the NFPA 286 fire test. In addition, they meet the California Department of Public Health VOC emissions standards, making them eligible for LEED credits. The tiles are also highly resistant to microbial and fungal growth, and they are an optimal choice for a variety of public or private spaces. Standard-sized Lay-In ceiling tiles have quick lead times and can be installed easily by dropping them into a standard 15/16” H.D. T-Grid. With a state-of-the-art manufacturing process, Envirocoustic Wood Wool Lay-In ceiling tiles are manufactured with even thicknesses, consistent dimensions, and clean, square edges.

The economical Envirocoustic Wood Wool Lay-In ceiling tiles not only liven up a room’s aesthetics with design variety and visual interest, but they can also be paired with a cellulose acoustical backer to improve the tiles’ acoustical performance.

Downloads / Product Resources

Product Data Sheet
Technical specifications Installation
Step by step guide CSI Specs
Industry standard format Test Reports
Acoustic, fire and material testing Sustainability Documents
For projects pursuing LEED, WELL, or LBC Misc. Data
SDS, warranty, care & maintenance

View All Resources

Product Specs

Applications

Schools and civic centers (gymnasiums, classrooms, auditoriums, music practice and band rooms), restaurants and bars, sports and entertainment venues, convention centers, houses of worship, shooting ranges, manufacturing and industrial facilities, parking garages, airports, and more.

Material Composition

Wood fiber, Portland cement, and water.

Wood fiber is a natural material, color variations may occur

Thickness

5/8"
1"
1" (Microstrand)
1-3/8"
2"

Size

Standard Sizes
23-3/4" x 23-3/4"
23-3/4" x 47-3/4"

Edge Detail

Square

Finishes

Primed Clear - natural wood color
Extra White - SW 7006 (Pro Industrial Waterborne Acrylic Dryfall)
Tricorn Black - SW 6258 (ProMar 200 Interior Latex - flat)
Stamped Concrete - SW 7665 (ProMar 200 Interior Latex - flat)
Custom Painted
Exterior paint (Duration Exterior Acrylic Latex) is available for exterior projects, please call for details
NOTE: Panel appearance and color will vary with the texture of the Wood Wool Fibers

Installation Method

Lay-in
Finish Options

Available Finish Options

Wood fiber is a natural material, color variations may occur

Standard Colors

Primed Clear

Extra White

Tricorn Black

Stamped Concrete

Custom Painted

Acoustical Specs

Envirocoustic™ Wood Wool – NRC Results
Panel Thickness	No Backer (E-400 Mount)	1″ CFAB Backer (E-400 Mount)	2″ CFAB Backer (E-400 Mount)
5/8″	0.50	0.90	0.95
1″	0.40	0.80	0.85
1″ (Microstrand)	0.55	0.90	0.95
1-3/8″	0.60	0.85	0.90
2″	0.75	0.95	0.95

Material Performance

Fire Performance

Class A Fire Rated per ASTM E84
Passes NFPA 286 Contribution to Room Fire Growth Test

Light Reflectance

Primed Clear - 50
Primed White - 76

Environmental

Passes CDPH Standard Method V1.2-2017 (VOC Emissions)
Passes ASTM D3273 test (100% clear of fungal growth)
Passes Mold Resistance test based on Greenguard Microbial Growth Test (Highly resistant to mold growth)

R-Value

1" R-Value: 2.32
2" R-Value: 3.74
