Acoustical Ceiling Tiles
Fabrisorb Shield™ Abuse Resistant Acoustical Panels
Extreme Abuse Resistant Absorptive Fabric Wrapped Fiberglass Panels
Fabrisorb Shield™ Abuse-Resistant Acoustical Panels deliver high-performance sound absorption with added protection for high-impact environments. Each panel features an extremely durable perforated copolymer layer over a fiberglass absorptive core to resist repeated contact while maintaining excellent acoustical performance. Available in multiple thicknesses, custom sizes up to 4’ × 10’, and a wide range of fabric options, these Class A fire-rated panels provide long-lasting durability for gyms, corridors, recreation spaces, and high-traffic facilities.
-
Product Specs
Applications
Gymnasiums, indoor sports courts, recreation centers, weight rooms, training facilities, locker rooms, corridors and hallways, cafeterias, multipurpose rooms, youth activity spaces, indoor playgrounds, transit
stations, detention and justice facilities, military training areas, warehouses, manufacturing spaces, amusement and entertainment centers, bowling alleys, trampoline parks, climbing gyms, batting cages, ice rinks, back‑of‑house hospitality areas, physical therapy gyms, rehabilitation centers, high‑traffic entryways and vestibules and more.Material Composition
Acoustically invisible fabric wrapped over an absorptive, 6-7 lb. p.c.f. fiberglass core and a 1/16” thick extremely abuse resistant perforated copolymer layer
Thickness
Standard: 1” & 2”
Optional: 9/16”, 1-9/16”, 3-1/16”, 4-1/16”Size
Standard: (2' x 2'), (2' x 4'), (4’ x 8’) and (4' x 8')
Most panels are custom made to suit - up to 4' x 10'Color
(standard): Guilford Anchorage and FR701 fabrics Additional options: Thousands of colors of fabrics (and various standard or micro-vented vinyl options) are available
Installation Method
Adhesive and impaling clips, Z-bars, Mechanical / RotoFast Anchors
-
Color Options
Acoustical fabric facings can be chosen from thousands of fabric optons. Our two standard fabrics are Guilford FR701 and Guilford Anchorage. We also frequently use a number of options from other fabric manufacturers. Note: Fabric pricing and availability varies significantly and not all fabrics are feasible. Please call for details.
-
Acoustical Specs
1-1/16″ Thickness NRC – .75 (D5 Mount)
2-1/16″ Thickness NRC – .95 (D5 Mount)
2-1/16″ Thickness NRC – 1.10 (F10 Mount)
Performance data derived from tests conducted according to ASTM C 423 on a Type D5 mounting by a NVLAP accredited laboratory. -
Material Performance
Fire Performance
Each component has been tested according to ASTM E 84 and has a Class A rating
Thermal Resistance (R-Value)
1″ – 4.1
2″ – 8.3
R-Value based on fiberglass coreEnvironmental
Fiberglass board core contains on average 35% recycled glass, with 9% post-consumer and 26% pre-consumer content.
