Quieting/Soundproofing Noisy Pipes

I came across Ted Weidman’s comment on
Soundproofing Apartment Wall regarding the flammability and toxicity of MLV. I have not been able to find information on this anywhere else (perhaps I don’t know where to look), I am wondering if materials used to insulate/soundproof pipes are made of similar materials? We are looking to soundproof a wall in between our very noisy shower pipes and my daughter’s bedroom, so the idea of using materials that would produce toxic fumes in a fire is a bit disconcerting to me. Thanks!

Thank you for the E-mail. I would be happy to discuss a few different approaches if you would like, so if you have time to call during the day, please feel free!!!

As far as blocking sound goes, if I could get a bit more information about the specifics of this one, it might help. Or, if you have the ability to take and E-mail a few digital pictures of the area, that might be a HUGE help! 😀 A picture is worth 1,000 words, right? 😀

Vinyl Fire Safety

As far as blocking the sound, are you treating the pipes inside of the wall, or do you have the ability to re-do the sheetrock in your daughter’s room? I will assume, for now, that you have opened up the wall and can only treat the area inside of the stud cavity. First of all, I know it sounds terrible, but don’t worry about the fumes in case of a fire. By the time the fire gets inside of the wall, so much other stuff has already burned and produced smoke it is a mute point. By this time everyone better already be out of the house and the fire trucks better be spraying. So, as long as the vinyl is IN the wall, it is a safe product to use. If, however, the vinyl was used as wallpaper, and the fire would be able to get to it FIRST, that’s another story.

Physically Securing The Pipes

Ok, with that out of the way, I can start explaining a bit about the products that you can use to treat the problem. The EXACT product and approach that I would suggest might change depending on the plumbing you are dealing with. You mentioned that you are trying to quiet down some “very noisy shower pipes” so for some reason, I assume you are dealing with old-school cast iron pipes. If this is the case, you can quiet them down a LOT by securing them to the wall properly. A lot of noise is created when the pipes move, physically – and hit the wood around them. Even just the vibration of the pipes makes noise and eliminating that can yield some surprising results. You might want to get a plumber or someone with plumbing experience involved with that, so you are sure to secure them properly as certain other metals will interact with the iron and corrode it quickly.

Use Acoustical Treatments

As far as acoustical treatment goes, I’ve got a few different products that might help and choosing exactly which one/ones for you might take a bit of discussion. Stopping sound and eliminating vibration are the same thing. So first, I would try to make sure the pipes are decoupled (not touching) the structure around them. This can be done with a high temp silicon type product or with rubber isolators. This way, when the pipes vibrate, the energy from the vibration doesn’t get into the wall. The second thing to do is to increase the mass/density that exists between the noise source and the potential listener. This is where the vinyl comes in. The vinyl is a technology that is designed to replace lead, very dense, heavy stuff. That mass and that density, coupled with the elasticity (rubbery like) vinyl turns the noise energy into heat energy as the vinyl resonates and moves. Think of a 5′ tall, super heavy punching bag. The weight of the bag absorbs the punch. If the bag were filled with packing peanuts, the bag would swing all over the place when you punch it.

Rather than wrapping the pipes directly with the vinyl, you are going to need some decoupler to make sure the vinyl doesn’t touch the pipes. That is done with one of the two following products:

  1. Barrier Decoupler, which is also called Pipe Lagging w/ decoupler
  2. B10LAG/QFA3 Pipe and Duct Lag

Both of these products will do the same thing, but each has its own advantage and disadvantage. If you are concerned with heat and/or smoke developed, I would go with the B10LAG as the fiberglass decoupler has a much higher heat tolerance than the other. I say both because the “Barrier Decoupler” and the “Pipe Lagging with decoupler” is the exact same product. Talk to the owner of my company about that one. They are both intended to be used by wrapping them directly around the pipe and securing them with fasteners like zip-ties and/or tape. Personally, I would use both because once that wall is closed you don’t want that stuff falling down. There is nothing wrong with overkill for installation as long as you don’t zip-tie the stuff so tight that the decoupler compresses and the vinyl touches the pipe.

Why the decoupler? The decoupler acts like a shock absorber and allows the vinyl to move and flex VERY slightly as the sound energy hits it. Think about the decoupler like a pillow and a cell phone on vibrate mode as the sound. If the phone is sitting on your kitchen table and it rings, the vibration easily transfers into the table. If the phone is sitting on a pillow, the vibration energy can’t get to the table because the pillow absorbs it. Same theory in the wall.Both of the products come in rolls that are 54′ wide. The lengths, as well as the costs, vary.

Use Ultra Touch Denim Insulation

Another product that will help is our Ultra Touch natural cotton fiber insulation. I used this product when I was remodeling a bathroom at a house that I’ve owned. This bathroom was on the other side of the wall from both bedrooms, and the wall that the shower/tub was on was against the same wall as the master bedroom. Being in the acoustics/soundproofing industry, of course, I was going to do what I could to eliminate the sound transmission – so I bought a couple of bundles of the Ultra Touch and stuffed it into the stud cavity. It helped tremendously. It is made from recycled cotton rather than fiberglass and has quite a bit more mass and density than fiberglass.

Ultra Touch

Ultratouch Stuffed Ultratouch Bathroom


6 Comments

  1. JR

    Hi Ted I’m looking to reduce the noise emanating from a plumbing waste pipe – when a toilet is flushed the gurgling sound can be easily and uncomfortably heard. So I was thinking of using the UltraSoft product wrapped around the pipe and within the wall cavity to address the issue. Unfortunately I’m having difficulty sourcing the UltraSoft product in my area so I was hoping you would recommend alternative products and/or solutions that would hep my situation?

  2. Ted W

    JR,
    Thanks for the post and question. Even after a few quick Google searches, I’m not familiar with this UltraSoft product but it sounds to me like it would be a “soft” light and fluffy fiberglass-insulation-like product to be stuffed into a wall. Is this the case? You may be thinking of the Ultra Touch insulation which is a cotton based insulation (//www.acousticalsurfaces.com/wall_insulation/ultratouch.htm?d=28)

    If this is a soft insulation type of product, I wouldn’t go this route if I were you. Insulation, weather it’s fiberglass, cotton, rock-wool, etc is light, soft, and fluffy and mostly air. Sound travels through air – so by nature, sound travels right through insulation. It is an incredibly common misconception that “insulation blocks sound” but it simply isn’t the case. Some companies even market “soundproof insulation” which, in my opinion, isn’t the right thing to do.

    Sound is blocked in a few ways – one of which being the more mass and density the better. Imagine the amount of sound blocked by a concrete bunker with 5′ thick concrete walls or an apartment wall made from two pieces of sheetrock and a stud. Clearly the concrete will block more. It is heavier.

    There are a few different products that can be wrapped around a pipe to help to contain that sound. These are typically roll-type products with some kind of soft material that should touch the pipe to keep the noise barrier off of the pipe wall. Most of these products on the market use a very dense, very heavy vinyl as the noise barrier. This vinyl is usually in the one-pound per square foot range. The most common product that we supply is a product called the Barrier-Decoupler which can be found here:
    //www.acousticalsurfaces.com/pipe_noise/piped.htm?d=14

    This product simply wraps around the pipe and is usually either overlapped or sealed for joining edges and then fastened with mechanical fasteners (zip-ties) and tape.

    If you have any further questions or if you would like a quote for some product, please feel free to contact me.

    Thank you!

    Ted Weidman
    Ted@acousticalsurfaces.com
    direct- 952-466-8225

  3. Jeff K

    Hi, and your blog questions/answers seem fit well with my situation: An upstairs bathroom toilet produces very loud water rushing noise in the house’s living room as the water descends through the waste line. My question is: What is the likelihood I’ll still be left with at least some water noise from the toilet/floor/joists/sheetrock connection, even after I do a super job on the waste line that’s connected to the toilet? The toilet has to be bolted to the bathroom floor, so how could I minimize noise transmission from toilet to floor to joists to studs to sheetrock?

    Jeff K

    • Ted W

      The question you pose is quite valid, and unfortunately there are always some limitations and things that are working against you in all situations. The bolts that hold the toilet in place are there and have a very important job. The thing that comes to mind would be potentially some kind of isolator bushing.

      As far as isolating the toilet from the subfloor – you might want to use some of the Acoustik, which is a flooring underlayment made out of recycled car tires.

      Let me know if you think either of these will work. Thanks,
      Ted

  4. CD

    We have the same problem with noisy shower pipes (they almost squeal when the shower is turned on). The shower is on the other side of our daughter’s back closet wall and she wakes up when my husband showers at 5:30am each morning. My question is whether there is any product that we can apply on the wall itself, rather than ripping out the existing sheet rock (due to the cost of having to get someone in to do the work and then the sheet rock repair). Thanks in advance!!

    • Ted W

      There is, unfortunately, no way to answer this question from the other side of a computer screen. The best and correct answer really depends on the nature of the problem. If the pipes are shaking/rattling and introducing a vibration energy into the structure, you are going to have to get into the wall and decouple the wall off the pipe from the structure – and probably put some kind of pipe wrap around the pipes themselves.

      Sometimes getting different faucets and fittings into the shower change the flow rate and hydrodynamics and eliminate the problem as well.

      Sorry I don’t have a better answer, that’s something you need to see/experience to try to offer recommendations.

      Thanks,
      Ted
