Sound Silencer™ Ceiling Tiles
Acoustical Ceiling Tiles
- Class A Fire Retardant
- No Fiberglass – Non-Fibrous
- Moisture Resistant – Indoor-Outdoor
- Impact Resistant
- Lightweight Sound Absorbing Ceiling Tiles
- Low VOC Emissions – Passes CDPH V1.2 Test Standard and can contribute to LEED V4.1 EQ Credit: Low-Emitting Materials
When soundproofing is essential for noise and sound control, Sound Silencer™ sound absorption ceilings and acoustical ceiling tiles provide the control you expect. Large noisy areas, such as gymnasiums and work floors can now be effectively managed with these acoustical ceilings and wall panels.
Product Testing & Information
- Product Data Sheet
- Installation Instructions
- CSI Specifications
- Testimonials
- Acoustical Test
- MSDS
- Flammability
- Product Photos
- Misc. Data
- CSI, CAD, and Revit Files
Product TAG
Color Options
Click on image for larger view of moisture resistant ceiling tiles.
Product Specs
Material
Semi Rigid Porous Expanded Polypropylene Acoustical Bead Foam (P.E.P.P.).
Pattern
Non-Abrasive, Slightly Textured, Porous
Features
These soundproofing ceiling tiles feature a lightweight, Impact Resistant, Moisture, Bacteria & Fungi Resistant, Tackable Surface
Applications
Use these sound dampening ceiling tiles for soundproofing ceilings of Gymnasiums, Auditoriums, Classrooms, Swimming Pools, Ice Arenas, Clean Rooms, Food Processing Plants, Food Prep Areas, Cafeterias & Restaurants, Manufacturing Plants, Car Washes, Rooftop and Machine Enclosures, Gun Ranges, Dog Kennels, Locker Rooms.
Thickness
1″ & 2″
Sizes
Exact Cut: 24″ × 24″, 24″ × 48″
Nominal: 23¾″ × 23¾″, 23¾″ × 47¾″
Custom Sizes Available – Maximum Acoustical Ceiling Panel Size: 25″ × 49″
Color
White, Charcoal
Flammability
ASTM E84, Class A. 1″ – Flame Spread: 3,Smoke Developed: 84. 2″ – Flame Spread: 5, Smoke Developed: 11 3
Installation
Glue on acoustical ceiling tiles directly or as a lay-in acoustical tile in a suspended t-bar grid system.
Weight
1″ – .25lbs/Sq ft; 2″ – .45lbs/Sq ft
| Sound Silencer™ Acoustic Ceiling Tiles – Sound Absorption/Noise Reduction | |||||||
|---|---|---|---|---|---|---|---|
| Tested Using Type E400 Ceiling Mounting | |||||||
| Thickness | 125Hz | 250Hz | 500Hz | 1KHz | 2KHz | 4KHz | NRC |
| 1″ | 0.46 | 0.59 | 0.42 | 0.49 | 0.76 | 0.86 | 0.55 |
| 2″ | 0.51 | 0.52 | 0.52 | 0.77 | 0.89 | 0.98 | 0.70 |
| Sound Silencer™ Acoustic Ceiling Tiles – Sound Transmission Loss (STC) | |||||||
|---|---|---|---|---|---|---|---|
| Thickness | 125Hz | 250Hz | 500Hz | 1KHz | 2.5KHz | 5KHz | STC |
| 1″ | 6 | 5 | 7 | 8 | 10 | 15 | 9 |
| 2″ | 9 | 8 | 10 | 10 | 17 | 22 | 13 |
| 1″ w/ 5/8″ Gypsum Both Sides | 27 | 27 | 29 | 31 | 32 | 45 | 32 |
