Acoustical Sound Barrier Ceiling Tile
Acoustical Sound Barrier Ceiling Tile

NOISE S.T.O.P.™ SOUND BARRIER ACOUSTICAL CEILING TILES

Super Sound Absorbing Ceilngs Tiles
Many Surfaces Options

  • High Acoustical Performance
  • Good Light Reflectance
  • Cost Effective – to Reduce Reverberation

Noise S.T.O.P.™ Sound Barrier Ceiling Tiles offer excellent acoustics with customized options to enhance the visual aesthetics, while satisfying acoustical requirements. Available in standard 2′×2′, 2′×4′ or custom sizes. Installs in T-Bar Grid.

Noise S.T.O.P.™ Sound Barrier Ceiling Tile features a 1 lb./sq. ft. foil-backed mass-loaded vinyl barrier laminated to 1″ and 2-1/8″ glass fiber core with white cleanable face. This tile offers high STC and NRC values and is available in a variety of finishes.

MATERIAL: Fiberglass core with F/G fabric facing.
APPLICATIONS: Any place where high performance acoustics is required.
SIZE: Nominal 2′×2′, 2′×4′ or custom sizes. Installs in T-Bar grid.
Part #
BARCT-122 – 1-1/8″ Thickness – 2′×2′
BARCT-222 – 2-1/8″ Thickness – 2′×2′
BARCT-124 – 1-1/8″ Thickness – 2′×4′
BARCT-224 – 2-1/8″ Thickness – 2′×4′
INSTALLATION: Lay-in grid
FLAMMABILITY: ASTM E-84 Class 1-A, Nonflammable.
PERFORMANCE: 2″ Thickness – NRC = 1.05, STC = 27; 1″ Thickness – NRC = .95, STC = 27

Edge Options
Barricade Ceiling Tile Square Edge Barricade Ceiling Tile Standard Reveal Edge
Square Edge
(Standard)
Standard Reveal Edge
(Optional)

Vibration Isolation Hanger Options
WHR Neoprene Hanger Isolation Hangers Fiberglass
WHR Neoprene Hangers Light Duty Isolation Hangers – Fiberglass


Click PDF iconPDF Iconto download printer friendly file format of product specs.

Click Acrobat Reader Icon to download a free copy of Adobe Acrobat Reader.
