Insul-Quilt

By absorbing environmental noises in the home and workplace, as well as in community, school, health and vacation settings, Insul-Quilt helps create more peaceful as well as efficient environments.

Insul-Quilt has emerged over and over again as the superior sound barrier when compared to even the newest state of the art sound absorbent materials.

Insul-Quilt is increasingly used today to enhance people’s quality of life by dramatically reducing the amount of unwanted noise that travels through walls and ceilings.

MATERIAL: Fiberglass core, faced with flame-proof foil.
THICKNESS: 2”
SIZES: 4' x 16' - Custom Length Available
WEIGHT: 28lbs Rolls
COLOR: White or Black Faced ( Custom colors available)
FLAMMABILITY: ASTM E84, Class A. Flame Spread: 0; Smoke Developed: 0
THERMAL CONDUCTIVITY: K Value = 12

Insul-Quilt.: Noise Reduction Coeficient - Type A

Frequency	125Hz	250Hz	500Hz	1KHz	2KHz	4KHz	NRC
	0.38	1.04	0.98	0.87	0.83	0.80	0.95

Insul-Quilt has gained a reputation among builders and architects for providing maximum environmental noise reduction. As a result many builders and architects began to use our Insul-Quilts in other projects. These include casinos, airport buildings, mixed-use buildings, retirement facilities, hospitals, schools, office buildings and apartment buildings, as well as hotels and vacation resorts. It is increasingly being used in structures at or near airports, freeways, and other high environmental noise areas.

Insul-Quilt is a state of the art material, which may not only be installed in plenums, but also can be installed directly on walls and ceilings. Weighing only .4 lbs. per square foot it is significantly lighter than most other professional grade materials, yet it absorbs in many cases as much as twice the noise as other materials.

Insul-Quilt is made of a blanket of glass-wool, faced with white fiberglass cloth and backed with aluminum foil. It is approximately two inches thick and four feet wide and is manufactured in varying lengths. Insul-Quilts can be manufactured to each individual client’s needs and even though the standard color-schemes are black and white fiberglass cloths, at our client’s request this cloth can be provided in numerous colors.

Insul-Quilt is a blanket of glass-wool, faced with white fiberglass cloth and backed with aluminum foil. It is two inches thick and four feet wide. It is manufactured at a standard length of 16 feet but can be customized to varying lengths. Insul-Quilts can be manufactured to each individual client’s needs and even though the standard color-schemes are black and white fiberglass cloths, at our client’s request this cloth can be provided in numerous colors.

Insul-Quilt serves not only as an acoustical and / or plenum barrier, but it also serves as excellent insulation. It is extremely safe due to its outer flame proof foil and received a flame spread and smoke density test result of zero by the SGS U.S. Testing Company Inc. in 2003.

Insul-Quilt has also gained a reputation among builders and architects for providing maximum environmental noise reduction in structures at or near airports, freeways and other high environmental noise areas. This amazing material has proven highly effective in casinos, vacation resorts, mixed-use buildings, office buildings, and hospitals.

Insul-Quilt is highly effective as a supplemental sound barrier in stopping the transfer of sound through ceilings and walls of adjacent rooms. It is also an excellent finish material for walls and ceilings while accomplishing maximum reduction in ambient noise. This state of the art material may not only be installed in plenums, but also can be installed directly on walls and ceilings

SAFETY INFORMATION

Insul-Quilt is extremely safe due to its outer flame proof foil and received a flame spread and smoke density test result of zero by the SGS U.S. Testing Company Inc. in 2003.

These results make Insul-Quilt a highly versatile and desirable sound-proofing and insulation material safe enough for any structure.

Insul-Quilt has been approved as an interior finish material by the City of Los Angeles Board of Building and Safety Commissioners of the City of Los Angeles.

Insul-Quilt is approved by the City of Los Angeles for installation in a plenum and meets the requirement for use in plenum under section 95.0105 and section 95.1002 of the Los Angeles Mechanical Code.
