Perforated Vinyl Ceiling Tile

perforated-vinyl-faced-backing

Acoustical Ceiling Tile

  • High Performance Acoustics
  • Light Weight

Product Testing & Information


Perforated Vinyl Ceiling Tiles
Barrier Backed Options
Perforated Vinyl Ceiling Tiles
Close up of Perforated Vinyl

Product Specs

Material

Semi-rigid fiberglass with perforated vinyl facing. Available with mass loaded vinyl barrier backer.

Sizes

Standard – Nominal 2′×2′, 2′×4′
Available in 4′×4′ and 4′×8′; Custom sizes also available.

Thickness

1" or 2"

Color

White

Applications

Ceiling tile applications where high acoustical performance is required.

Weight

0.5 lb/sf for 1″, 1 lb/sf for 2″

Flammability

Per E-84, 25 f/s, Smoked Developed 50

Light Reflectance

LR-1 (actual .87)

Thermal Resistance

1″ = R-4

Maintenance

Easily cleaned with soft brush or vacuum.

Reverberation Demonstration

Perforated Vinyl Ceiling Tile – Noise Reduction Coefficient
Mount 125Hz 250Hz 500Hz 1KHz 2KHz 4KHz NRC
1″ E .69 .95 .85 1.06 1.11 1.08 .95
